HF Ac Dc Aluminum Tig Welder

Lewei Pumps Industry Co., Ltd. is one of the leading manufacturers and suppliers of hf ac dc aluminum tig welder in China, also supports customized service. Please feel free to wholesale advanced hf ac dc aluminum tig welder for sale here from our factory. Quality products and reasonable price are available.









The TIG 250M is a universal TIG bow which will connect to any constant current AC or DC MMA welding power source, giving you excellent TIG welding performace at low cost. Used with an AC output MMA welding set such as an oil cooled or air cooled transformer based welding machines and some engine driven type machines it will weld aluminium and its alloys.



Used with a DC output MMA welding set such as an inverter, engine driven welder generators & rectifier type power sources it will weld mild steel, stainless steel, copper & other metals.





Key features

►Connects to any constant current AC or DC MMA welding power source

►Built in gas post flow to give good finish without contamination of the weld

►Duty cycle - 200A @ 60%

►Heavy duty contactor built in to provide start and stopping of the welding arc

►Electronic high frequency





Technical Specifications

►Welding current range - 20A - 200A

►Duty cycle - 200A @ 60%

►Max current - 250A

►Input supply - 220V

►Welding rod - 1.6-5.0mm





Features

►AC/DC welding depending upon power source, this allows a wide range of materials to be welded.

►Electronic High Frequency to initiate and stabilize the welding arc.

►Torch trigger to normal and latch functions.

►Power connections to take standard TIG torches.

►Built in gas post flow to give good finish without contamination to the weld.

►Heavy duty contactor built in to provide start and stopping of the welding arc.









Product Model:	TIG-250M
Rated Input Voltage:	1phase, 220V +/- 15%
Input Capacity:	9.3KVA
Frequency:	50/60Hz
No-load Voltage:	55V
Rated Duty Cycle:	60%
Efficiency:	85%
Class of Insulation:	F
Protection Level:	IP21S
Output Current:	MMA/ARC/STICK	20-160A
	MIG/MAG/FLUX	Not Available
	TIG	20-200A
Function Support:	HOT START	Available
	ANTI STICK	Available
	ARC FORCE	Available
	PULSE WELDING	Available
	Package Dimension	600x340x440mm
	Package Weight	25Kg
