Air Plasma Cutter Machine
2. Easy and simple operation panel
3. Smooth cutting surface.
4. Suitable for cutting stainless steel, copper, iron and aluminum metal etc.
Lewei Pumps Industry Co., Ltd. is one of the leading manufacturers and suppliers of air plasma cutter machine in China, also supports customized service. Please feel free to wholesale advanced air plasma cutter machine for sale here from our factory. Quality products and reasonable price are available.
Product Description
Air plasma cutter machine, also known as a plasma cutter, is a device that uses a high-temperature plasma arc to cut through various types of conductive materials.
Adopt with advanced IGBT inverter technology, and accord with EMC standard.It is an exceptional machine that is suitable for a wide range of applications including sheet metal fabrication, light industrial use, site work, automotive, ducting work, repair and maintenance services.
A air plasma cutter machine generates a high-temperature plasma arc by passing a gas, such as compressed air or nitrogen, through a small channel. The arc then cuts through the metal by melting it and blowing away the molten material.
This air plasma cutter machine is specifically designed for cutting applications and cannot be used for welding. However, it is often used in conjunction with welding machines to prepare the materials for welding.
Technical Data
|
Product Model: |
CUT-120P |
CUT-160P |
|
Rated Input Voltage: |
3phase, 380V +/- 15% |
3phase, 380V +/- 15% |
|
Input Capacity: |
15KVA |
29KVA |
|
Frequency: |
50/60Hz |
50/60Hz |
|
No-load Voltage: |
70V |
70V |
|
Rated Duty Cycle: |
60% |
60% |
|
Efficiency: |
85% |
85% |
|
Power Factor:(cosφ) |
0.93 |
0.93 |
|
Class of Insulation: |
F |
F |
|
Protection Level: |
IP21 |
IP21 |
|
Output Current: |
20-100A |
20-160A |
|
Cutting thickness(mm): |
1-35 |
1-50 |
|
Package Dimension: |
695x450x590mm |
695x450x590mm |
|
Packing: |
CARTON |
CARTON |
|
Package Weight: |
42KG |
46KG |
Certification
